2399 Digital Delay Line
Digital Delay Effects based on PT2399 Chip
v0.1
Specifications
| Parameter | Value |
|---|---|
| Width | 10HP |
| Depth | ~35mm max. skiff friendly |
| +12 Current | - |
| -12 Current | - |
| +5 Current | 0mA |
Features
- PT2399-based delay effect with wide range of delay times
- Two audio inputs and outputs to allow for feedback loops
- Time CV control with attenuator
- High pass filter & (high pass) bypass switch
Quirks and Problems
- Adjusting input level for second input slightly affects the level of the first input
- High pass filter is routed the wrong way, so turning it clockwise will lower the cutoff point
- High pass filter does not cover the whole frequency range
